Complete Online Moisture System: Sensor, Software, and Training in One Package
Everything needed to put moisture measurement on a production line and act on it. The KJT330 sensor head over the line, a processor unit and PC running Kett Tracker in the control room, and the cabling, connectors, and operator training to make it work from day one.
Contact Kett for Pricing
A sensor on its own is only part of the job. Calibrations have to be built, results have to go somewhere useful, and someone has to know how to run it. The KJT350 packaged all of that: the KJT330 sensor head, a processor unit and PC with Kett Tracker software, every cable and connector needed, and operator training.
The head measures from 350 mm above the surface across a 50 mm spot, with no contact and no sampling, and responds in approximately two seconds. Its aluminum casting is dust proof and drip proof, and the tungsten lamp and filter motor are both rated at 20,000 hours. The processor unit ships desktop or panel mount, and analog output drives your existing control loops directly. Purge enclosures and cooling systems were available for hose down areas and high ambient temperatures.
Each system shipped with Kett’s One Year Total Care Warranty covering parts, labor, and specification compliance. Maintenance Agreements are available.
The KJT350 is no longer manufactured. It succeeded the KJT300 system and was built around the KJT330 sensor head.
Need a complete online moisture system for your line today? The KJT703 Instant Online Moisture Meter is the current online moisture platform, delivered configured for your product and process.
| Weight | 35 lbs |
|---|---|
| Dimensions | 22 × 18 × 14 in |
| Measurement Principle | Near-Infrared Reflectance |
| Measurement Range | 0.000–99% (product dependent) |
| Accuracy | ±0.001% (reference method dependent) |
| Resolution | 0.001% |
| Reproducibility | 0.001% |
| Response Time | Approximately 2 seconds, analog output. Averaging time constant selectable 0–99 seconds. |
| Refresh Rate | 0.2 seconds per output, 0.5 seconds per display update |
| Applications | Moisture |
| Measurable Components | Moisture |
| Form Factor | Online |
| Measurement Diameter | Approximately ø50 mm |
| Measurement Distance | 350 mm ±50 mm |
| Number of Wavelengths | 1 plus reference |
| Light Source | Tungsten lamp |
| Sensor Type | Reflectance sensor head with lead sulfide detector in an aluminum casting, dust proof and drip proof, with air purge hood |
| Throughput / Capacity | Up to four sensor heads per processor board. Multiple boards managed from one PC. |
| Display | Red seven segment LED on the sensor head. Processor unit adds a seven segment LED plus a backlit LCD showing analytical curve data and error messages. |
| Measurement Modes | Continuous monitoring with selectable averaging, channel selection by keypad or external contact input |
| Compensation Functions | Temperature compensation, humidity compensation via the sensor integrated in the air purge hood, and analytical curve offset compensation |
| Features | Zero adjustment, analytical curve offset correction, upper and lower moisture alarms, self diagnostics, error code reporting |
| Data Memory Capacity | 99 analytical curves per sensor head. Relational database storage, trending, and reporting in Kett Tracker on the PC. |
| Calibration Curves Available | Up to 99 per sensor head, built by regression against user reference values using linear, quadratic, or cubic fit |
| Safety Features | Sensor head high and low temperature alarms, motor rotation error, low reflectance error, calculation and memory error reporting |
| Operating Temperature | 0–40°C at the installation site |
| Operating Humidity | 10–80% RH, non-condensing |
| Communications | RS-422 between sensor head and processor unit, standard. Alarm output standard. RS-232C to PC and 4–20 mA recorder output available as factory options. |
| Power | 100–120 VAC or 200–240 VAC, 50/60 Hz, selected at time of shipment |
| Power Consumption | 52 VA sensor head, 16 VA processor unit |
| Dimensions | Sensor head 291 × 150 × 192 mm, 440 mm overall with snout. Desktop processor unit 148 × 320 × 254 mm (W × D × H). |
| Weight | Sensor head 7.5 kg (16.5 lbs) including air purge hood. Processor unit 6.2 kg (13.7 lbs). |
| Standard Accessories | KJT330 sensor head, air purge hood with humidity compensation sensor, zero adjustment plate, processor unit, Kett Tracker software, cables and connectors, operator training |
| Options | Additional sensor heads up to four per processor board, interface cards, junction boxes, purge enclosure, cooling systems, traverse and scanning frame, panel mount processor unit |
| Warranty | One Year Total Care Warranty covering parts, labor, and specification compliance. Maintenance Agreements available. |
